Heimvision IP camera URL

Connecting to your Heimvision IP camera*


Try the following connection options in iSpy or Agent to connect to your Heimvision IP camera. If an FFMPEG option is available we recommend you try that first as it will often be faster and include audio support. You can also try the VLC plugin if the FFMPEG option isn't working.

The settings for Heimvision cameras are built right into our free surveillance software - click "Add" then "IP camera with wizard" to automatically setup your Heimvision cameras. Remember to also try connecting via ONVIF as Heimvision cameras may support ONVIF connections as well.

Start typing in the "Make" box to find your camera. If your camera is not listed then click "Get Latest List" in settings or when on the add camera wizard. If you need to modify the URL then add or edit the Heimvision camera and you can modify the connection type and URL in the video source dialog (button is top of the first tab).

Heimvision compatible software*

Download Heimvision compatible software

Tip: Click a model to generate a URL for your camera

ModelsTypeProtocolPath
201, hm202A, Protect D1 HM612 PTZFFMPEGrtsp:///ch0_0.h264
201, HM 241, hm202A, hm203, hm311, hme311, PTZFFMPEGrtsp:///h264_stream
241, HM 241JPEGhttp://cgi-bin/snapshot.cgi?chn=[CHANNEL]&u=[USERNAME]&p=[PASSWORD]
311VLCrtsp://ch0_0.h264
311, HM311FFMPEGrtsp:///user=[USERNAME]&password=&channel=1&stream=0.554
311, Protect ID1FFMPEGrtsp:///0
ca1JPEGhttp://snapshot.jpg
cloudcam, hm202A, HM311FFMPEGrtsp:///0/av0
CloudCam, hm202A, HM211, hm311, Protect D1, Protect D1 HM612 PTZFFMPEGrtsp:///MainStream
CloudCam, hm202A, hm203, hm311, Other, Protect D1, Protect D1 HM612 PTZFFMPEGrtsp:///user=[USERNAME]_password=[PASSWORD]_channel=1_stream=0.sdp
CLOUDCAM, HM203, Protect D1, PTZFFMPEGrtsp:///
HM 241, HM541JPEGhttp:///cgi-bin/snapshot.cgi?chn=1&u=[USERNAME]&p=[PASSWORD]
HM 241, WirelessJPEGhttp:///cgi-bin/snapshot.cgi?chn=2&u=[USERNAME]&p=[PASSWORD]
HM 241JPEGhttp:///cgi-bin/snapshot.cgi?chn=3&u=[USERNAME]&p=[PASSWORD]
HM 245FFMPEGrtsp://user=[USERNAME]&password=[PASSWORD]&channel=1&stream=0.sdp?
hm202A, OtherFFMPEGrtsp:///cam/realmonitor?channel=1&subtype=00&authbasic=[AUTH]
hm202A, HM311FFMPEGrtsp:///0/av1
hm203FFMPEGrtsp:///live
hm203FFMPEGrtsp:///11
hm211FFMPEGrtsp:///SubStream
hm241JPEGhttp:///cgi-bin/snapshot.cgi?chn=0&u=[USERNAME]&p=[PASSWORD]
hm311FFMPEGrtsp:///onvif1
mh612FFMPEGrtsp:///live/av0
OtherFFMPEGrtsp://live
OtherFFMPEGrtsp://mpeg4/media.amp
PTZFFMPEGrtsp:///1/h264major
Page:
1

* iSpyConnect has no affiliation, connection, or association with Heimvision’s products. The connection details provided here are crowd sourced from the community and may be incomplete, inaccurate or both. We provide no warranty that you will be successful using these connection URLs or that Heimvision products are compatible with iSpy.
