Onvif IP camera URL

Connecting to your Onvif IP camera*


Try the following connection options in iSpy or Agent to connect to your Onvif IP camera. If an FFMPEG option is available we recommend you try that first as it will often be faster and include audio support. You can also try the VLC plugin if the FFMPEG option isn't working.

The settings for Onvif cameras are built right into our free surveillance software - click "Add" then "IP camera with wizard" to automatically setup your Onvif cameras. Remember to also try connecting via ONVIF as Onvif cameras may support ONVIF connections as well.

Start typing in the "Make" box to find your camera. If your camera is not listed then click "Get Latest List" in settings or when on the add camera wizard. If you need to modify the URL then add or edit the Onvif camera and you can modify the connection type and URL in the video source dialog (button is top of the first tab).

Onvif compatible software*

Download Onvif compatible software

Tip: Click a model to generate a URL for your camera

ModelsTypeProtocolPath
001111, 23344, 380, 3805P, 3851, 4312B, 49336059, 57ii, Cotier_TV631W-ip, d53m02, DONPHIA, Euronet, GW5050IP, ipc6200, IPD-E2A5L18-BS, Jidetech, m2-p488, Main, NAUM, NAUM2, NAUM3, ONVIF CAMERA, ONVIF_IPNC, Other, patton, POE-661B, PROVISION ISR, SC3V-1, techma, TH32E-ONVIF, V380, v380 pro, V380-Q10FFMPEGrtsp:///mpeg4
342, 5MPtopsee, 5MPTOPSEE, 960p, 960Pchina spot 2019, d53m02, diamond, gw security 5mg, gwsecurity 5mb, ipc6200, IPC-F20M, IPD-E2A5L18-BS, JH720e1, LBH30SE200W4, lsvision, model 2000, ONVIF_IPNC, Other, rhbr, Secureye, westmile, zsvdrFFMPEGrtsp:///mpeg4cif
5MPTOPSEE, Other, VNcamMJPEGhttp://cgi-bin/video.cgi?msubmenu=mjpg
9411, DomeCam, DONPHIA, eyeonet4k, Other, PROVISION ISR, Sibell IP, Techson S1Pro52030IM, tvtFFMPEGrtsp:///profile1
AK-HD54F245, gate 1, granstream, MC400L, NDR-405-P-BGZ20, oma, ONVIF_IPNC, Other, PTXDome1, PTZ, S3VC, sc3v, SV-B06POE-1080P-A, V380FFMPEGrtsp:///stream0
DOMECAM, IPC, Other, PTZFFMPEGrtsp:///0
DOMECAM, IPC-model, Other, Other_onvif, profile s, PTZ, S3VC, SC3V-1, VESKYSJPEGhttp://snap.jpg?JpegCam=[CHANNEL]
IpcFFMPEGrtsp:///profile2
ipc2122FFMPEGrtsp:///h264_stream
IPC-HDBW4431R-ZS, IPHD, Other, PTZJPEGhttp://cgi-bin/snapshot.cgi?chn=[CHANNEL]&u=[USERNAME]&p=[PASSWORD]
IPG-7920PHM-AI/T7H, Other, QD900, V380FFMPEGrtsp:///live/0/MAIN
MC400LJPEGhttp://cgi-bin/snapshot.cgi?loginuse=[USERNAME]&loginpas=[PASSWORD]
Model S, Other, v380, V380VLCrtsp://live/ch00_0
NLISTED, OtherJPEGhttp://snapshot.jpg?account=[USERNAME]&password=[PASSWORD]
ONVIF CameraJPEGhttp://cgi-bin/CGIProxy.fcgi?cmd=snapPicture2&usr=[USERNAME]&pwd=[PASSWORD]
OtherJPEGhttp://cgi-bin/CGIProxy.fcgi?cmd=snapPicture2&usr=[USERNAME]&pwd=[PASSWORD]&
Other, TH38M-ONVIF-P2PMJPEGhttp://videostream.cgi?user=[USERNAME]&pwd=[PASSWORD]&resolution=32&rate=0
OtherFFMPEGrtsp:///cam/realmonitor
Other, Profile S, PTZ, SC3V-1JPEGhttp://tmpfs/auto.jpg
OtherJPEGhttp://snapshot.jpg?user=[USERNAME]&pwd=[PASSWORD]
OtherFFMPEGrtsp:///profile0
PTZ, PTZ1, YN-AJ8079R-POEFFMPEGrtsp:///stream1
Shenzhen Jiaxinjie Technology Co. LtdFFMPEGrtsp://h264
TH38M-ONVIF-P2P, VESKYSJPEGhttp://img/snapshot.cgi?size=2
VeskysFFMPEGrtsp:///tcp/av0_0
WeirdFFMPEGhttp://videostream.asf?usr=[USERNAME]&pwd=[PASSWORD]
Page:
1

* iSpyConnect has no affiliation, connection, or association with Onvif’s products. The connection details provided here are crowd sourced from the community and may be incomplete, inaccurate or both. We provide no warranty that you will be successful using these connection URLs or that Onvif products are compatible with iSpy.
