Canon's VB-series network cameras served professional and commercial surveillance. Models stream over HTTP and RTSP on port 80; Agent DVR connects with a direct stream URL — click any model below to build it. Connect your Canon camera to Agent DVR for free local recording, object detection and secure remote viewing.
Canon connection URLs
Tip: Click a model to generate a video connection URL for your Canon camera
| Models | Type | Protocol | URL |
|---|---|---|---|
| 740, CRN-300, VB-M50B | FFMPEG | RTSP | /stream/profile2=r |
| CN-R500, CR-N500, M42, m44, vb-610, VB-C10, VB-C300, VB-C50i/C50iR, VB-C60, VB-H41, VB-H43, VB-H45, VB-h610, VB-H610VE, VB-H630VE, VB-H710F, VB-H730F, VB-M40, VB-M42, VB-M44, VB-M50B, VB-M600D, VB-M620VE, VB-M700F, VB-M720F, VBS30D, VB-S30D, VB-S30VE, VB-S805D, VB-S900F, VB-S905F, VB-M46, CR-N100 | MJPEG | HTTP | /-wvhttp-01-/video.cgi |
| CRN-300, VB-M720F | MJPEG | HTTP | /-wvhttp-01-/GetOneShot?image_size=320x240&frame_count=0 |
| DC210 | MJPEG | HTTP | /?&AUDIO=YES&CHOPIMAGE=YES&STREAM=YES&WANTIMAGE=[CHANNEL].JPG&SENDEMPTYIMAGES=NO |
| i50, VB300, VB-C10, VB-C300, VB-C500D, VB-C50FSi, vb-c50i, VB-C50i/C50iR, VB-C60, vb-h41, VB-H43, VB-H630, VB-H630VE, VB-M40, VB-M42, VB-M50B, VBS30D, VB-S900F | JPEG | HTTP | /-wvhttp-01-/GetOneShot?image_size=[WIDTH]x[HEIGHT] |
| Unknown | VLC | RTSP | /cam[CHANNEL]/h264 |
| Unknown | VLC | HTTP | /vdata.v |
| vb150, VB-C10, vb-c10r, VB-C300, VB-C50Fi, VB-C50FSi, vb-c50i, VB-C50i/C50iR, VB-C60, VB-M40, VB-M42, VB-M600D | MJPEG | HTTP | /-wvhttp-01-/GetOneShot?image_size=[WIDTH]x[HEIGHT]&frame_count=0 |
| VB-C10, VB-C300, VB-M40 | JPEG | HTTP | /-wvhttp-01-/GetLiveImage |
| VB-C300 | VLC | RTSP | |
| vb-h41, vb-h630, VB-H710F, VB-M42, VB-M50B, VB-M720F, VB-S900F, VB-S905F | FFMPEG | RTSP | /stream/profile1=r |
| VB-H43, VB-S800D | FFMPEG | RTSP | /stream/profile0=r |
| VB-M40 | VLC | RTSP | /profile1=u |
| VB-M600D | VLC | RTSP | /profile1=r |
| VB-M720F, VB-R12VE | JPEG | HTTP | /-wvhttp-01-/GetOneShot?image_size=320x240 |
| VB-S900F | FFMPEG | HTTP | /viewer/admin/index.html?lang=en |
| VB-S900F | FFMPEG | RTSP | / |
Page
1* iSpyConnect has no affiliation, connection, or association with Canon’s products. The connection details provided here are crowd sourced from the community and may be incomplete, inaccurate or out of date. We provide no guarantee or warranty that you will be able to connect to your cameras using these URLs.
How to connect Canon cameras to Agent DVR
- Download and install Agent DVR — free for local use on Windows, macOS, Linux, Docker and Raspberry Pi.
- Open Agent DVR in your browser and click the + (Add) button, then choose "IP Camera Wizard".
- Select Canon from the manufacturer list.
- Enter your camera's IP address, username and password. These stay on your machine and are never sent to iSpyConnect.
- Pick the RTSP connection URL (default port 554) and save. Agent DVR begins live streaming, motion detection and recording.
Canon Camera FAQ
How many Canon camera models does iSpyConnect support?
iSpyConnect's crowd-sourced database lists 48 Canon models with 16 connection URLs, updated daily by the community.
What is the RTSP URL for Canon cameras?
Canon cameras typically connect over RTSP on port 554. For example, the Canon 740 connects at rtsp://[camera-ip]:554/stream/profile2=r — replace [camera-ip] with your camera's address and add your username and password, or click any model in the table above to generate the exact URL.
Do Canon cameras support ONVIF?
It varies by model. If your Canon camera supports ONVIF, Agent DVR can auto-discover it; otherwise use a direct RTSP URL from the table above.
How do I connect Canon cameras to Agent DVR?
Install Agent DVR (free), click the + button, choose the IP Camera Wizard, select Canon, enter your camera's IP address, username and password, then pick a connection URL. Agent DVR starts live streaming, motion detection and recording immediately.
