This section covers Insteon home-automation cameras catalogued by the community. Models stream over HTTP and RTSP, often on port 88; Agent DVR connects with a direct stream URL — click a model below to generate it with your credentials. Add an Insteon camera to Agent DVR for free local recording, motion detection and remote viewing.

24 modelsRTSP · HTTPPort 58741Updated 9 Jun 2026
Agent DVR is free for personal, local use. Download Now Remote access or business use → Pricing

insteon connection URLs

Tip: Click a model to generate a video connection URL for your insteon camera

Models Type Protocol URL
1010, 2864, 4020a2, 602, 75790, 75790WH, 75791, 78790, FR4020A2FFMPEGHTTP/videostream.asf?user=[USERNAME]&pwd=[PASSWORD]&resolution=[WIDTH]x[HEIGHT]
2846, 2864-222, 2864226, 2864-226, 2864-22x, 2864-232, 75790wh, UnknownFFMPEGRTSP/videoMain
2864, 2864-232, 4020a, 4020a2, 75790, 75790/75790wh, 75790mew, 75790wh, 75791, a61689, F19821W, FR4020A2FFMPEGHTTP/videostream.asf?user=[USERNAME]&pwd=[PASSWORD]&resolution=64&rate=0
2864, 2864-222, 75790, 75790/75790WH, 75790WH, 75791, OIPC-10VLCHTTP/videostream.asf?user=[USERNAME]&pwd=[PASSWORD]
2864-222, 2864-226, 2864-22x, 2864-232, 4020a2, 75790, 75790WH, 75791, 75799, F19821WJPEGHTTP/cgi-bin/CGIProxy.fcgi?cmd=snapPicture2&usr=[USERNAME]&pwd=[PASSWORD]&
2864-222, 2864-232, 75790/75790WH, 75790WHFFMPEGHTTP/videostream.asf?user=[USERNAME]&pwd=[PASSWORD]&resolution=[WIDTH]*[HEIGHT]
2864-222, 2864-226JPEGHTTP/cgi-bin/CGIProxy.fcgi?cmd=snapPicture2&usr=[USERNAME]&pwd=[PASSWORD]
2864-222, 2864-232JPEGRTSP/videoSub
75790, 75790WHFFMPEGHTTP/videostream.asf?user=[USERNAME]&pwd=[PASSWORD]&resolution=32&rate=0
75790, 75790/75790WH, 75790wh, 75791JPEGHTTP/snapshot.jpg?user=[USERNAME]&pwd=[PASSWORD]&strm=[CHANNEL]
75790, 75790/75790WHJPEGHTTP/snapshot.cgi?usr=[USERNAME]&pwd=[PASSWORD]
75790, 75790/75790WH, 75790WH, 75791MJPEGHTTP/video.cgi?resolution=[WIDTH]x[HEIGHT]
75790, 75790/75790WHMJPEGHTTP/videostream.cgi?user=[USERNAME]&pwd=[PASSWORD]&resolution=32&rate=0
75790, 75790whMJPEGHTTP/videostream.cgi?user=[USERNAME]&pwd=[PASSWORD]
75790, 75790WHMJPEGHTTP/videostream.cgi?rate=0&user=[USERNAME]&pwd=[PASSWORD]
75790MJPEGHTTP/videostream.cgi?user=[USERNAME]&pwd=[PASSWORD]&resolution=32&rate=0
75790MJPEGHTTP/videostream.cgi
75790, 75790WHFFMPEGHTTP/videostream.asf?usr=[USERNAME]&pwd=[PASSWORD]
75790/75790WH, 75790WHMJPEGHTTP/videostream.cgi?rate=11
75790/75790WHJPEGHTTP/image/[CHANNEL].jpg
FR4020A2FFMPEGHTTP/videostream.asf
oc821JPEGHTTP/img/snapshot.cgi?size=2
UnknownFFMPEGHTTP/videostream.asf?user=[USERNAME]&pwd=[PASSWORD]&resolution=320x240
Page
1

* iSpyConnect has no affiliation, connection, or association with insteon’s products. The connection details provided here are crowd sourced from the community and may be incomplete, inaccurate or out of date. We provide no guarantee or warranty that you will be able to connect to your cameras using these URLs.

How to connect insteon cameras to Agent DVR

  1. Download and install Agent DVR — free for local use on Windows, macOS, Linux, Docker and Raspberry Pi.
  2. Open Agent DVR in your browser and click the + (Add) button, then choose "IP Camera Wizard".
  3. Select insteon from the manufacturer list.
  4. Enter your camera's IP address, username and password. These stay on your machine and are never sent to iSpyConnect.
  5. Pick the RTSP connection URL (default port 58741) and save. Agent DVR begins live streaming, motion detection and recording.

insteon Camera FAQ

How many insteon camera models does iSpyConnect support?

iSpyConnect's crowd-sourced database lists 24 insteon models with 23 connection URLs, updated daily by the community.

What is the RTSP URL for insteon cameras?

insteon cameras typically connect over RTSP on port 58741. For example, the insteon 2846 connects at rtsp://[camera-ip]:58741/videoMain — replace [camera-ip] with your camera's address and add your username and password, or click any model in the table above to generate the exact URL.

Do insteon cameras support ONVIF?

It varies by model. If your insteon camera supports ONVIF, Agent DVR can auto-discover it; otherwise use a direct RTSP URL from the table above.

How do I connect insteon cameras to Agent DVR?

Install Agent DVR (free), click the + button, choose the IP Camera Wizard, select insteon, enter your camera's IP address, username and password, then pick a connection URL. Agent DVR starts live streaming, motion detection and recording immediately.
